Just trying "impossible things" with POV-Ray... :)
--
Jaime
Post a reply to this message
Attachments:
Download 'test-car3m-1.jpg' (32 KB)
Download 'test-car3m-2.jpg' (39 KB)
Download 'test-car3m-3.jpg' (40 KB)
Preview of image 'test-car3m-1.jpg'
Preview of image 'test-car3m-2.jpg'
Preview of image 'test-car3m-3.jpg'
|
|
| |
| |
|
|
|
|
| |
| |
|
|
I 'briefly' considered rendering the unconscious form of the troll in Harry
Potter; then thought it was more waste than the toadstool that began the
thread you reference.
Good show!
- Grim
Post a reply to this message
|
|
| |
| |
|
|
|
|
| |
| |
|
|
Have you done it all with POV-Ray?
"Jaime Vives Piqueres" <jai### [at] ignorancia org> escribió en el mensaje
news:41d6e53a@news.povray.org...
> Just trying "impossible things" with POV-Ray... :)
>
> --
> Jaime
>
>
--------------------------------------------------------------------------------
--------------------------------------------------------------------------------
--------------------------------------------------------------------------------
Post a reply to this message
|
|
| |
| |
|
|
|
|
| |
| |
|
|
Great! Those remind me of a car I used to see around here, it was painted
bright metallized orange, and it was quite conspicuous under the summer
sun.
--
light_source{9+9*x,1}camera{orthographic look_at(1-y)/4angle 30location
9/4-z*4}light_source{-9*z,1}union{box{.9-z.1+x clipped_by{plane{2+y-4*x
0}}}box{z-y-.1.1+z}box{-.1.1+x}box{.1z-.1}pigment{rgb<.8.2,1>}}//Jellby
Post a reply to this message
|
|
| |
| |
|
|
|
|
| |
| |
|
|
of course not
Post a reply to this message
|
|
| |
| |
|
|
|
|
| |
| |
|
|
Jellby wrote:
> Great! Those remind me of a car I used to see around here, it was painted
> bright metallized orange, and it was quite conspicuous under the summer
> sun.
There was, I believe a paint used on some Mitsubishi Eclipse's (mid-late
90's vintage) that was a burnt orange from one angle, and an olive from
a different angle. Very interesting to look at, but I wouldn't want to
own one.
Post a reply to this message
|
|
| |
| |
|
|
|
|
| |
| |
|
|
Jaime Vives Piqueres <jai### [at] ignoranciaorg> wrote:
> Just trying "impossible things" with POV-Ray... :)
>
> --
> Jaime
Jaime,
Nice renders, care to share the texture you are using?
Thanks,
Sean
Post a reply to this message
|
|
| |
| |
|
|
|
|
| |
| |
|
|
Jaime Vives Piqueres wrote:
> Just trying "impossible things" with POV-Ray... :)
>
> --
> Jaime
>
Very nice. Knowing your previous work, I expect that the "defects" near
the phong highlights are probably due to the JPEG compression. Love to
see the pictures at a higher resolution.
On a different note. Although they are not quite visible here, how do
you make your numberplates? Are they CSG or blobs? I'm especially
interested in the letters and numbers. I've been looking for a font that
mimics the dutch numberplate font, because I wanted to make customisable
numberplates. Haven't found one yet :-( It's a pity that every european
country uses it's own font.
Great work,
--
Maurice
Welcomes everybody to the fifth year of the century.
Post a reply to this message
|
|
| |
| |
|
|
|
|
| |
| |
|
|
Maurice wrote:
> Very nice. Knowing your previous work, I expect that the "defects" near
> the phong highlights are probably due to the JPEG compression. Love to
> see the pictures at a higher resolution.
No, these defects are the triangles of the car mesh, I think, showing
badly in some places.
> On a different note. Although they are not quite visible here, how do
> you make your numberplates?
It's a height_field, as all I've found was a jpg image with all the
chars and numbers (in a site about miniature car modeling). The font
used in Spain is also very rare and I cannot find anything even remotely
similar...
> Great work,
Thanks!
--
Jaime
Post a reply to this message
|
|
| |
| |
|
|
|
|
| |
| |
|
|
Oleguer Vilella wrote:
> Have you done it all with POV-Ray?
No, the car is modeled with Wings3D and the environment is made with
photos mapped on boxes. But the car paint is 100% POV-Ray procedural
textures.
--
Jaime
Post a reply to this message
|
|
| |
| |
|
|
|
|
| |
| |
|
|
Salty wrote:
> Nice renders, care to share the texture you are using?
Of course no... I will put some example on my site soon, but bellow
is the texture itself. The idea is very simple, and the effect can be
controlled playing with the specular amount of the first layer and the
transmit value on the second.
#declare rmin=.1;
#declare rmax=.33;
#declare c1=Blue*.25; #declare c2=Green*.5;
//#declare c1=Red*.125; #declare c2=Yellow*.5;
//#declare c1=Blue*.2+Green*.1; #declare c2=Yellow*.5;
//#declare c1=Violet*.5; #declare c2=Red;
//#declare c1=Red*.5; #declare c2=Green;
//#declare c1=Black; #declare c2=White;
//#declare c1=Black; #declare c2=Red;
//#declare c1=Blue*.5; #declare c2=Orange;
//#declare c1=Black; #declare c2=Aquamarine;
//declare c1=Black; #declare c2=Blue*.7+Green*.3;
#declare t_custom_paint=
texture{
pigment{rgb c2}
finish{specular 2 metallic roughness .1 brilliance 10}
}
texture{
pigment{rgb c1 transmit .33}
finish{
specular 1 roughness .0125
diffuse 1-rmax reflection{rmin,rmax} conserve_energy
//irid{.25 thickness pi/2} // :)
}
}
--
Jaime
Post a reply to this message
|
|
| |
| |
|
|
|
|
| |
| |
|
|
Jaime Vives Piqueres wrote:
> Maurice wrote:
>
>> On a different note. Although they are not quite visible here, how do
>> you make your numberplates?
>
>
> It's a height_field, as all I've found was a jpg image with all the
> chars and numbers (in a site about miniature car modeling). The font
> used in Spain is also very rare and I cannot find anything even remotely
> similar...
Now there's something I hadn't thought of. I could just take some
pictures of plates and thus collect all the characters and define a
height_field for each. Thanks for the idea.
--
Maurice
Post a reply to this message
|
|
| |
| |
|
|
|
|
| |
| |
|
|
"Michael Raiford" <mra### [at] hotmailcom> wrote in message
news:41d771e6$1@news.povray.org
> Jellby wrote:
>> Great! Those remind me of a car I used to see around here, it was
>> painted bright metallized orange, and it was quite conspicuous
>> under the summer sun.
>
> There was, I believe a paint used on some Mitsubishi Eclipse's
> (mid-late 90's vintage) that was a burnt orange from one angle, and
> an olive from a different angle. Very interesting to look at, but I
> wouldn't want to own one.
I saw a green/purple version of this, looked stunning.
Post a reply to this message
|
|
| |
| |
|
|
|
|
| |
| |
|
|
Hi all!
Dunno who it was, but I saw very interesting metallic car painting a year
ago or so, maybe more. It was rendered in MLpov, the paint colour was
AOI-dependent. Moreover there were some fine metal particles visible in the
coat. Tried to search the POV-Ray Newsgroup to no avail. There was also
quite nice animation - the futuristic car speeding through the city. I
thought that stunning procedural paint would look cool with this magnificent
piece of model. Does anybody remember that thread and possibly give a hint?
Excellent modelling Jaime
Matt Burns
Post a reply to this message
|
|
| |
| |
|
|
|
|
| |
| |
|
|
All right, many thanks.
Regards,
Oleguer
"Jaime Vives Piqueres" <jai### [at] ignoranciaorg> escribió en el mensaje
news:41d83e9b$1@news.povray.org...
> Oleguer Vilella wrote:
>> Have you done it all with POV-Ray?
>
> No, the car is modeled with Wings3D and the environment is made with
> photos mapped on boxes. But the car paint is 100% POV-Ray procedural
> textures.
>
> --
> Jaime
Post a reply to this message
|
|
| |
| |
|
|
|
|
| |
| |
|
|
Jaime Vives Piqueres <jai### [at] ignoranciaorg> wrote:
> Salty wrote:
> > Nice renders, care to share the texture you are using?
>
> Of course no... I will put some example on my site soon, but bellow
> is the texture itself. The idea is very simple, and the effect can be
> controlled playing with the specular amount of the first layer and the
> transmit value on the second.
>
> #declare rmin=.1;
> #declare rmax=.33;
> #declare c1=Blue*.25; #declare c2=Green*.5;
> //#declare c1=Red*.125; #declare c2=Yellow*.5;
> //#declare c1=Blue*.2+Green*.1; #declare c2=Yellow*.5;
> //#declare c1=Violet*.5; #declare c2=Red;
> //#declare c1=Red*.5; #declare c2=Green;
> //#declare c1=Black; #declare c2=White;
> //#declare c1=Black; #declare c2=Red;
> //#declare c1=Blue*.5; #declare c2=Orange;
> //#declare c1=Black; #declare c2=Aquamarine;
> //declare c1=Black; #declare c2=Blue*.7+Green*.3;
>
> #declare t_custom_paint=
> texture{
> pigment{rgb c2}
> finish{specular 2 metallic roughness .1 brilliance 10}
> }
> texture{
> pigment{rgb c1 transmit .33}
> finish{
> specular 1 roughness .0125
> diffuse 1-rmax reflection{rmin,rmax} conserve_energy
> //irid{.25 thickness pi/2} // :)
> }
> }
>
> --
> Jaime
Erk? Gotta play around some with this...
I thought from some way back discussions in these newsgroups that finishes
in layered textures always ended up being the last one used.
I've been making layered textures with a finish only on one texture. You
mean that I could have been layering finishes too?
<Whump!> (sound of head beating wall)
RG
Post a reply to this message
|
|
| |
| |
|
|
|
|
| |
| |
|
|
gonzo wrote:
> Erk? Gotta play around some with this...
It has room for a lot of playing... depending on the colors to mix,
you will need to adjust the specular and the transmit values.
> I thought from some way back discussions in these newsgroups that finishes
> in layered textures always ended up being the last one used.
No, that was normals. The tutorial even warns about not confusing it
with finishes... :)
> I've been making layered textures with a finish only on one texture. You
> mean that I could have been layering finishes too?
Hmmm.... yes, sorry... ;) (I've suffered such "subconscious
assumptions" sometimes, even with the most obvious things).
--
Jaime
Post a reply to this message
|
|
| |
| |
|
|
|
|
| |
| |
|
|
Matt Burns wrote:
> Dunno who it was, but I saw very interesting metallic car painting a year
> ago or so, maybe more. It was rendered in MLpov, the paint colour was
> AOI-dependent. Moreover there were some fine metal particles visible in the
> coat. Tried to search the POV-Ray Newsgroup to no avail. There was also
> quite nice animation - the futuristic car speeding through the city. I
> thought that stunning procedural paint would look cool with this magnificent
> piece of model. Does anybody remember that thread and possibly give a hint?
The only thing I found was Tek metallic paint macro, searching for
pov+metallic+paint. Thanks for the hint: I had borrowed some bits from
Tek approach.
> Excellent modelling Jaime
Thanks!
--
Jaime
Post a reply to this message
|
|
| |
| |
|
|
|
|
| |
| |
|
|
Jaime Vives Piqueres a écrit :
> Salty wrote:
>
>> Nice renders, care to share the texture you are using?
>
>
> Of course no... I will put some example on my site soon, but bellow
> is the texture itself.
Thank you very much, Jaime. Now I have a very beautiful metallic texture
for my big truk. :)
--
ZeSly
http://perso.wanadoo.fr/zesly/
Post a reply to this message
Attachments:
Download 'bigtruck3.jpg' (92 KB)
Preview of image 'bigtruck3.jpg'
|
|
| |
| |
|
|
|
|
| |
| |
|
|
ZeSly wrote:
> Thank you very much, Jaime. Now I have a very beautiful metallic texture
> for my big truk. :)
Wow! I'm glad to have contributed to that ambitious project: the
level of detail is amazing! I will have to ask you for help when
designing my first truck (I would like to do a "busy freeway" scene in
the future).
--
Jaime
Post a reply to this message
|
|
| |
| |
|
|
|
|
| |
| |
|
|
I think these paintings are called "pearlescent" or "luster"
paintings. Some car manufacturers call them "mica" where mica
is a low refractive index material used for one of the two
or three layers these paintings have.
-Hans-
